CNCTOPBAOS Integrated Nema23 Closed Loop Stepper Motor 1.5N.m 5A DC24V-50V
US$18.20
Price when purchased online
Free shipping
Free 30-day returns
Sold and shipped by www.thienthientan.vn
We aim to show you accurate product information. Manufacturers, suppliers and others provide what you see here.
US$18.20
Price when purchased online
Free shipping
Free 30-day returns
Sold and shipped by www.thienthientan.vn
Free 30-day returns Details
Product details
| Management number | 250262884 | Release Date | 2026/09/17 | List Price | US$18.20 | Model Number | 250262884 | ||
|---|---|---|---|---|---|---|---|---|---|
| Category | |||||||||
- Specifications: Type: Nema23 Integrated Closed loop Stepper Motor; Rated Torque: 1.5N.m; Encoder line: 1000; Motor size: 57x57x74mm; Shaft Diameter: 8mm; Input: DC24-50V,recommended DC36V; Current: 5A; Max. frequency: 300KHZ; Weight: 1.63LB
- Integrated design: The integrated closed-loop stepper motor integrates the driver and motor body together, simplifying the system structure and reducing the difficulty of installation and maintenance
- Standard Pulse and Direction Control – Industry‑Standard Interface The motor accepts standard Pulse + Direction signals via the high‑speed input interface (PUL+/PUL‑, DIR+/DIR‑), with a maximum input frequency of 300kHz. This makes it fully compatible with PLCs, motion controllers, microcontrollers, and CNC systems—seamlessly integrating into your existing automation architecture
- High performance control: Adopting closed-loop control technology, precise control of the motor is achieved by feeding back the position and speed information of the motor, improving the stability and accuracy of the system. The closed-loop motor effectively reduces the out of step phenomenon of the stepper motor, improves the positioning accuracy of the system, and its torque is also larger than that of ordinary stepper motors
- Widely used: including CNC machines, industrial automation, and robotics technology,t hey are applied in joint drives, end effectors and other parts to achieve high-precision and high-speed motion control; Automated production line: used for equipment such as conveyor belts; Medical device field and other precision manufacturing equipment, etc
| ASIN | B0DZBK4V96 |
|---|---|
| Model | JDS |
| Brand Name | CNCTOPBAOS |
| Item Weight | 0.21 kg |
| Part Number | JDS |
| Manufacturer | Changzhou Rattm Motor Co.,Ltd |
| Material Type | Aluminum |
| Item Highlight | All-in-one Motor, Multi-Microstep, 8mm Shaft, 3000RPM, 300KHz,1000-Line Encoder for CNC Machine,Robotics,Industrial Automated |
| Number of Items | 3 |
| Included Components | motor |
